Stainless Steel Tube

ASTM A249 Stainless Steel Welded Tubes For Heat - Exchanger and Condenser Standard:ASTM A249 Material:TP304/304L, TP316/316L other material is also avaliable. Type one: Pickling Pipe Type two:Bright Annealed Tube O.D. 0.23'-80'(5.8-2032mm) O.D. 6-50.8mm W.T. 0.01'-1.125'(0.25-28mm) W.T. 0.71-3.68mm Length according to clients' request Length 6-24m Standard JIS DIN GB BS ASTM(ASME) etc. Standard ASTM A249, etc. Surface Finish Annealed,Polish,Brush etc. Surface Finish right

ASTM A268 Seamless and Welded Ferritic and Martensitic Stainless Steel Pipes Applications: For general service Technique: Cold-Formed and Hot Rolled Size range: O.D. 4-230mm W.T. 1-30mm Length max 12000mm Characteristic: Good concentricity Good OD and ID tolerance High Precision Stable quality Smooth Roughness TORICH QUALITY ASSURANCE Chemical Composition: Grade: TP4 05 TP4 10 TP2 49 TP4 30 TP4 43 TP4 46-1 TP4 46-2 … TP4 09 UNS S40500 S41000 S42900 S43000 S44300 S44600 S44600

ASTM A270 TP304, TP316, 2205, 2507, 2003 Stainless Sanitary Tubing Welded Austenitic Stainless Steel Tube For Healthcare Material ASTM A270 specifies the requirements for stainless steel sanitary tubing used primarily in the healthcare, pharmaceutical, and food industries. The tubing must be made from austenitic stainless steels known for corrosion resistance, durability, and cleanliness. Common materials under ASTM A270 include: TP304 (Austenitic Stainless Steel) TP316

ASME SA 789 UNS S32750 Welded Tube & Duplex Stainless Steel Pipe Supplier The duplex material is a kind of ferrite - austenitic duplex stainless steel,which is integrated conducive properties both of ferrite and austenitic and provided with higher intensity as well as tenacity. Size Chart OD Wall (inch) Materials Standard Working Pressure (MPa) Length 1/8" 0.02,0.028,0.035 Austenitic steel 304L (UNS S30403) Austenitic steel 316L (UNS S31603) Duplex 2205 (UNS S32205 & S31803)

Alloy 2205 Seam Welded Pressure Tubing duplex 2205 tube The duplex material is a kind of ferrite - austenitic duplex stainless steel,which is integrated conducive properties both of ferrite and austenitic and provided with higher intensity as well as tenacity. Delivery Condition: 1.Annealed and Pickled 2.Bright and Annealed 3.Annealed and Pickled+Polishing 4.Bright and Annealed+Polishing CHEMICAL COMPOSITION: UNS Chemical , % C Mn P S Si Ni Cr Mo N S31803 0.030MAX 2.00MAX 0

Seamless and welded super duplex 2507 oil gas stainless coiled tubing Applications: For oil transport, chemical engineering Technique: Cold worked and hot worked Alloy or not: Alloy Secondary or not: Non-Secondary Steel Grade/Steel Material: Material 200 series: 201, 202 300 series: 304, 304L, 304H, 310S, 316, 316L, 317L, 321,310S,309S,2205,2507,2520 400 series: 410, 410S,420, 430, 431, 440A,904L Size range: O.D. 8-530mm W.T. 0.5mm-30mm Length max 12000mm Characteristic: Good

Black Seamless And Welded Rolled Steel Pipe Product Description Standard ASTM A268 Material TP405, TP410, TP430, TP446-1, TP446-2, 26-3-3, other material is also available O.D. 3.2 - 200 mm W.T. 0.5 - 30 mm Length Max 12000 mm Chemical Composition Grade UNS C Mn P S Ni Cr Mo N TP410 S41000 0.15 max 1.00 max 0.040 max 0.030 max --- 11.5-13.5 --- --- S42035 0.08 max 1.00 max 0.045 max 0.030 max 1.0-2.5 13.5-15.5 --- 0.30-0.50 TP430 S43000 0.12 max 1.00 max 0.040 max 0.030 max -

Seamless Tubing ASTM A632 Welded Austenitic Stainless Steel Tubes Product Decription Standard: ASTM A632 Material: TP304/304L/310/316/316L. Size Range: O.D.: 1.27 - 12.7 mm W.T.: 0.10 - 2 mm Length: As per client requested. Chemical Composition,% Element/Grade TP304 TP304L TP310 TP316 TP316L C, max 0.08 0.030 0.25 0.08 0.030 Mn, max 2.00 2.00 2.00 2.00 2.00 P, max 0.045 0.045 0.045 0.045 0.045 S, max 0.030 0.030 0.030 0.030 0.030 Si, max 1.00 1.00 1.00 1.00 1.00 Ni 8.0 - 11.0

Ferritic Seamless And Welded Tubing ASTM A268 TP410 Stainless Steel Tube Product Description Standard ASTM A268 Material TP405, TP410, TP430, TP446-1, TP446-2, 26-3-3, other material is also available O.D. 3.2 - 200 mm W.T. 0.5 - 30 mm Length Max 12000 mm Chemical Composition Grade UNS C Mn P S Ni Cr Mo N TP410 S41000 0.15 max 1.00 max 0.040 max 0.030 max --- 11.5-13.5 --- --- S42035 0.08 max 1.00 max 0.045 max 0.030 max 1.0-2.5 13.5-15.5 --- 0.30-0.50 TP430 S43000 0.12 max 1
