U-bochtbuis
ASTM B395 U-buigbuis C68700 C71500 C68700
TORICH ASTM B395 Cold Drawn Seamless Copper Alloy Tubes C68700 C71500 C68700,Copper Pipe U Bend Introduction: Product name Cold drawn seamless U bend tube OD 5-420mm WT 0.5-50mm Usage Heat exchanger, condenser, heaters Section shape Round Technics Cold drawn Type Seamless QUALITY CONTROL: 1. Incoming Raw Material Inspection 2. Raw Material Segregation to avoid steel grade mix-up 3. Heating and Hammering End for Cold Drawing 4. Cold Drawing and Cold Rolling, on line inspection
Lichtgetrokken U-bocht Koperen Buis
ASTM B395 ASTM B111 C71500 C44300 H96 H62 H55 light-drawn U Bend Copper Tube Condenser and Heat Exchanger Tube Name seamless copper (nickel) pipe Standard ASME SB165, SB111, etc. Material C10100, C10200, C12000, C28000, C12200, C44300(brass alloys), C70600(90-10), C68700(CZ110 Aluminium barss alloy), C71500(70-30), C71640(66-30-2-2),etc. OD 6-219.1mm WT 0.7-12.7mm Length 0-38000mm Surface treatment solution annealing/Light Draw/Stress Relieving Heat Treatment Test requirement
De Buis Koudgetrokken Lage Koolstof van de Astma179 Naadloze U-bocht voor Condensator 0,6 - 30mm GEWICHT
ASTM A179 Seamless Cold-Drawn Low-Carbon U-Bend Steel Pipes for Condenser Applications: Heat-Exchanger and Condenser Tubes Size range: O.D.:15-600mm W.T.:0.6-30mm L: according to customer requirement Steel Grade and Chemical Compositions: C 0.06-0.18 Mn 0.27-0.63 P ≤0.035 S ≤0.035 Mechanical Properties Tensil Streghth: min ksi[Mpa] 47[325] Yield Point: min ksi[Mpa] 26[180] Elongation: ≥35% Hardness: ≤72HRB How is your production capability? 1.2000 tons monthly production
15mm U-bochtbuis
U bend Tubes Stainless Steel ASTM ASME SA213 TP316 U-bent Tubes for Heat Exchanger Underfloor Heating Tube Grage: Austenitic stainless steel u bent tube 201/202/301/304/304L/316/316L/321 Ferritic stainless steel pipe/tube 409/430/439/441/443/436L/444/445J1/445J2/445J3/S44660/447 Duplex stainless steel pipe/tube S31803/S32750 Size: stainless steel pipe Φ6.35 Φ8.0 Φ9.5 Φ10 Φ12.7 Φ15.88 Φ19.1Φ 20.0Φ 22.2 Φ25.4 Φ31.8 Φ38.1 Φ40 Φ42.7 Φ50.8 Φ63.5 Φ76.2 Φ88.9 Φ101 Thickness
Lage Naadloze het Staalbuis van de KoolstofWarmtewisselaar, de U-bochtbuizen van ASTM A179
Low Carbon Heat Exchanger Seamless Steel Tube , ASTM A179 U Bend Tubes PRODUCT DETAILS : Standard:ASTM A179 ASME A179Material:Carbon SteelType:U BendingProduction:Cold DrawnApplication:Heat Exchangers,Cold CondensorsDimension:OD 15.88-114mm ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat Exchanger Tubes and Condenser Tubes Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger Tubes and Condenser Tubes Applications:For BoilersSuperheatersHeat-ExchangersCondensers U bend
ASTM A179 A192 naadloze U-buigbuizen van koolstofstaal met drukdragende structuur en gecontroleerde U-buiggeometrie voor warmtewisselaars
ASTM A179 A192 U Bend Tubes For Heat Exchanger Shell Product Overview ASTM A179 / ASTM A192 U bend tubes are seamless carbon steel tubes manufactured for shell-and-tube heat exchangers, boilers, condensers, and similar thermal equipment where compact bundle design, reliable pressure resistance, and stable heat-transfer performance are required. ASTM A179 is typically selected for seamless cold-drawn low-carbon heat exchanger and condenser tubing, while ASTM A192 is used for
S235JR gegalvaniseerde U-vormige structuurstaalpijpen voor de bouw
S235JR U-Shaped Structural Steel Pipe Galvanized Carbon Steel Pipe for Construction This product is a galvanized carbon steel structural component manufactured from S235JR non-alloy structural steel. It is designed for construction projects that require dependable load-bearing capacity, good weldability, easy fabrication, and improved outdoor corrosion resistance through hot-dip galvanizing. In practical supply, S235JR is the base steel grade under EN 10025-2, while the
ASTM A179 Koudgetrokken Naadloze Lage Koolstofstalen U-bochtbuis voor Warmtewisselaars
ASTM A179 U-Bend Tube — Cold-Drawn Seamless Low-Carbon Steel Tubing for Heat Exchangers Material ASTM A179 U-bend tubes are seamless, cold-drawn low-carbon steel tubes that are formed into a U-shape for shell-and-tube heat exchangers, condensers, coolers, and similar heat-transfer equipment. The base tube is produced by the seamless process and cold drawing, then bent to the required radius/leg length with strict control of dimensional stability and surface condition.
ASTM B395 naadloos U-bend koperbuis voor warmtewisselaartoepassingen
ASTM B395 U-Bend Seamless Copper & Copper-Alloy Tubes for Heat Exchangers Material ASTM B395/B395M U-bend tubes are 180°-bent, seamless tubes used in condensers, evaporators, and heat exchangers, manufactured from seamless copper and copper-alloy tube. The specification applies to tubes ≤ 2 in. (50 mm) OD and covers common heat-transfer alloys including oxygen-free copper (C10200), phosphorus-deoxidized copper (C12200), admiralty/aluminum brass (C44300/C68700), and copper
