Legeringsnikkel - baseer Inconel-Buis Hoge Zuiverheid Inconel 718 Buizenstelsel 1634.4 σB/MPa

Basis eigenschappen
Plaats van herkomst: China
Merknaam: Torich
Certificering: CE PED
Modelnummer: Inconel 718
Handelsgoederen
Minimale bestelhoeveelheid: 1000kg
Prijs: 6000-20000 USD per ton
Betalingsvoorwaarden: L / C, T / T
Toeleveringsvermogen: 200 ton per jaar
Productoverzicht
Inconel-staalbuis met Inconel-staal van legeringInconel 718 Mechanisch onderdeel: Standaardkwaliteit Hoge zuiverheid C: ≤ 0.080.02-0.06 0.02-0.06 Cr:17.0-21.0 17.0-21.0 17.0-21.0 Ni:50.0-55.0 50.0-55.0 50.0-55.0 Co:≤1,0 ≤1,0 ≤1.0 Mo:2.8-3.3 2.8-3.3 2.8-3.3 Al:0.3-0.7 0.3-0.7 0.3-0.7 Ti:0.75-1.15 0...

Productdetails

Markeren:

Inconel 600 Buis

,

inconel buis 718

Productbeschrijving

Inconel-staalbuis met Inconel-staal van legeringInconel 718

Mechanisch onderdeel:

Standaardkwaliteit Hoge zuiverheid

C: ≤ 0.080.02-0.06 0.02-0.06

Cr:17.0-21.0 17.0-21.0 17.0-21.0

Ni:50.0-55.0 50.0-55.0 50.0-55.0

Co:≤1,0 ≤1,0 ≤1.0

Mo:2.8-3.3 2.8-3.3 2.8-3.3

Al:0.3-0.7 0.3-0.7 0.3-0.7

Ti:0.75-1.15 0.75-1.15 0.75-1.15

NB:4.75-5.505.0-5.50 5.0-5.50

B:0.006 max 0,006 max 0,006 max

Mg:0.01 max.01 max0.005 max.

Monometers0.35 max 0,35 max 0,35 max

Si:0.35 max 0,35 max 0,35 max

P:0.015max 0.015max 0.015max

S:0.015 max 0.015 max0.002 max.

Cu:0.30 max 0,30 max 0,30 max

Ca:0.01 max.01 max0.005 max.

Pb:0.5 max0.001max 0.001max

- Ja.0.3 max 0,3 max 0,3 max

Kenmerkend:

Inconel718 superlegering met nikkelbasis.

In het bereik van -253-700°C met een goede algemene prestatie

Een goede vermoeidheids-, stralings-, oxidatie-, corrosiebestendigheid, goede verwerkingseigenschappen, lasprestaties, langdurige organisatiestabiliteit.

ToepassingHet gaat om ruimtevaart, kernenergie, olie-industrie, enzovoort in een breed scala van toepassingen.

InconelX-718 mechanische eigenschappen.

Specificatie

d / mm

Stijl van bemonstering

θ/°C

met een breedte van niet meer dan 50 mm

HBS

Duurzame prestaties

σP0.2/MPa

σb/MPa

δ5/%

ψ/%

σ/MPa

t/h

δ5/%

≤ 125

Portret

20

650

1030

860

1280

1

12

12

15

15

≥ 346

---

---

690

---

≥ 25

---

≥ 5

126 tot 200

Transversaal

20

650

1030

860

1240

965

6

6

8

8

---

---

---

690

---

≥ 25

---

---

> 200

Transversaal

20

650

1020

800

1230

900

6

6

8

8

---

---

---

690

---

≥ 25

---

---

- Ik weet het niet.

Gevolgen van de temperatuur op de trekkracht van warmgewalste staven.

Temperatuur / °C

Treksterkte

σb / MPa

Kracht van de uitlaat

σP0,2/MPa

Verlenging/% Krimp/%
- 195 jaar.5 1634.4 1196.5 26.0 27
- 51 jaar.1 1389.6 1089.6 23.0 33.5
26.6 1313.7 1058.6 22 32.5
648.8 1134.4 999.9 28.0 59.2
704.4 1003.4 917.2 22 34
