de Cilinder van 61X50 DIN2393 st52-3 DOM Steel Tube For Hydraulic Telescobic
Basis eigenschappen
Plaats van herkomst:
China
Merknaam:
Torich
Certificering:
ISO 9001 TS 16949
Modelnummer:
DIN2393
Handelsgoederen
Minimale bestelhoeveelheid:
2tons
Prijs:
onderhandelbaar
Betalingsvoorwaarden:
L/C, T/T
Toeleveringsvermogen:
5000tons per jaar
Productoverzicht
61X50 DIN2393 ST52-3 DOM-staalbuizen voor hydraulische telescopische cilinders Snelle details. Materiaal:1020 St52-3 Q345B Grootte: 63*52 80*68 98*85 116*103 135*121 154.5*140 175 maal 159.5 197*180 220*202 mm Tolerantie van OD: (+1,2/1,8 mm) Tolerantie van ID: ((0,-0,2 mm) Lange: naar uw wensen. ...
Productdetails
Markeren:
Hydraulische Telescobic-Cilinder DOM Steel Tube
,St52-3 DOM Steel Tube
,Precisie Dom Mechanical Tubing
Technique:
Koudgetrokken
Thickness:
1 - 60 mm
Application:
Hydraulische Pijp
Standard:
ASTM
Section Shape:
Ronde
Alloy Or Not:
Non-alloy
Secondary Or Not:
Niet secundair
Outer Diameter(Round):
30 - 250 mm
Length:
volgens de verzoeken van klanten
Shape:
ronde
Productbeschrijving
61X50 DIN2393 ST52-3 DOM-staalbuizen voor hydraulische telescopische cilinders
Snelle details.
Materiaal:1020 St52-3 Q345B
Grootte:
63*52
80*68
98*85
116*103
135*121
154.5*140
175 maal 159.5
197*180
220*202 mm
Tolerantie van OD: (+1,2/1,8 mm)
Tolerantie van ID: ((0,-0,2 mm)
Lange: naar uw wensen.
Rechtheid ≤ 0,3/1000 mm
ovale buis ≤0.1
Trekweerstand ≥ 640 MPa
Vermogen ≥ 550Mpa
Verlenging ≥ 12%
Hardheid 80-100HRB -20°C 27J 100% Ultrasone foutdetectie
St52-3 Stalen plaat Chemische analyse
| Chemische elementen | C ≤ 16 mm max | C> 16 mm max | - Jawel. max. | Maximale | P Max. | S Max. |
| %,in massa | 0.24 | 0.24 | 0.55 | 1.60 | 0.045 | 0.045 |
Gebeurtenis:
Hoge tolerantie
Goed oppervlak
Hoge prestaties op mechanische eigenschappen
Snelle levertijd
