Astm A513 om Precisie SAE 1020 Dom Steel Tube
Basis eigenschappen
Plaats van herkomst:
China
Merknaam:
Torich
Certificering:
ISO9001 TS16949
Handelsgoederen
Minimale bestelhoeveelheid:
1 ton
Betalingsvoorwaarden:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Toeleveringsvermogen:
50000 ton per jaar
Productoverzicht
ASTM A513 Precision DOM Steel Tube Productbeschrijving: 4.7mm 6.6mm 0.185in 0.26in Precision SAE 1020 ASTM A513 DOM buizen Kenmerkend: Goede concentriciteit Goede tolerantie voor OD en ID Hoge nauwkeurigheid Stabiele kwaliteit Glanzige ruwheid TORICH Kwaliteitsborging Productieprocessen: ERW-buis en ...
Productdetails
Markeren:
dom van SAE 1020 staalbuis
,DOM van ASTM A513 Staalbuis
Material:
SAE 1020
Certification:
ISO9001 TS16949
Type:
Koudgetrokken, Koude Tekening
Shape:
Ronde Vorm
Size:
OD 4420mm WT0.5-50mm
Surface Treatment:
Het oli?en
Productbeschrijving
ASTM A513 Precision DOM Steel Tube
Productbeschrijving:
4.7mm 6.6mm 0.185in 0.26in Precision SAE 1020 ASTM A513 DOM buizen
Kenmerkend:
Goede concentriciteit
Goede tolerantie voor OD en ID
Hoge nauwkeurigheid
Stabiele kwaliteit
Glanzige ruwheid
TORICH Kwaliteitsborging
Productieprocessen:
ERW-buis en koudtrekken of koudwalsen
Grenswaarden voor de chemische samenstelling, %
| Groepsbenaming | Carbon | Mangan | Fosfor, max. | Zuur, max. |
| MT1010 | 0.05-0.15 | 0.30-0.60 | 0.035 | 0.035 |
| MT1015 | 0.10-0.20 | 0.30-0.60 | 0.035 | 0.035 |
| BT-verbinding | 0.10-0.20 | 0.60-0.90 | 0.035 | 0.035 |
| MT1020 | 0.15-0.25 | 0.30-0.60 | 0.035 | 0.035 |
| MT X 1020 | 0.15-0.25 | 0.70-1.00 | 0.035 | 0.035 |
