Van de het Nikkellegering van OD12.0mmhastelloy C276 Speciale het Staalpijp
Basis eigenschappen
Plaats van herkomst:
CHINA
Merknaam:
Torich
Certificering:
IS09001 ISO14001 TS16949
Modelnummer:
ASTM B622 626 619
Handelsgoederen
Minimale bestelhoeveelheid:
0,5 ton
Prijs:
onderhandelbaar
Betalingsvoorwaarden:
L/C, T/T
Toeleveringsvermogen:
60000tons per jaar
Productoverzicht
Naadloze stalen buizen van Hastelloy C276 nikkellegering Snelle details. Overdosis:3.18-114.3 mm WT:0.5-12 mm StandaardASTM B574 BACEMR0175 ASME SB 574 ASTM B622 Standard:ASTM B622 ASTM B619 Chemische samenstelling: % Ni Cr Mo. Fe W Co. C Deeltjes - Jawel. P S V Min. Remian 20 12.5 2.0 2.5 Maximaal ...
Productdetails
Markeren:
Pijp van het Hastelloyc276 de Speciale Staal
,De Legeringspijp van het Hastelloyc276 Nikkel
,OD12.0mm de Pijp van de Nikkellegering
Standard:
ASTM B622 626 619
Material:
Hastelloy C276
OD:
12.076.2mm
WT:
0.512.0mm
Denisity:
8.69g/cm3
Productbeschrijving
Naadloze stalen buizen van Hastelloy C276 nikkellegering
Snelle details.
Overdosis:3.18-114.3 mm
WT:0.5-12 mm
StandaardASTM B574 BACEMR0175 ASME SB 574 ASTM B622
Standard:ASTM B622 ASTM B619
Chemische samenstelling:
| % | Ni | Cr | Mo. | Fe | W | Co. | C | Deeltjes | - Jawel. | P | S | V |
| Min. | Remian | 20 | 12.5 | 2.0 | 2.5 | |||||||
| Maximaal | 22.5 | 14.5 | 6.0 | 3.5 | 2.5 | 0.015 | 0.50 | 0.08 | 0.020 | 0.020 | 0.35 |
Fysieke eigenschappen
Densiteit:80,69 g/cm3
Smeltpunt:1325-1370°C
Mechanische eigenschappen
Treksterkte: 794Mpa min
Gewichtssterkte: 402 MPa min
Verlenging: 60%
Hardheid ((HB):195HB
Gelijksoortig materiaal
legering C276 UNS nr. N10276
legering C22 UNS nr. N06022
legering 59 UNS.N06259.
legering B2 N10665
legering 400 N04400
legering 201 N02201
legering 20 N08020
legering 825 N08825
legering 625 N06625
legering 600 N06600
legering 601 N06601
legering 800H/HT N08811
legering 617 N06617
legering X N06002
