Duplex het Roestvrije staalbuis van DN200 ASTM A790 F51/van F55/van F53/van F60
Basis eigenschappen
Plaats van herkomst:
China
Merknaam:
Torich
Certificering:
ISO9001 ISO14001 TS16949
Modelnummer:
ASTM A790
Handelsgoederen
Minimale bestelhoeveelheid:
5 ton
Prijs:
Negoticable
Betalingsvoorwaarden:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Toeleveringsvermogen:
500 ton per maand
Productoverzicht
DN200 ASTM A790 F51 / F55 / F53 / F60 Duplex roestvrijstalen buis Productnaam: DN200 ASTM A790 F51 / F55 / F53 / F60 Duplex roestvrijstalen buis Standaard: ASTMA790 Materiaal: SS201/301/302/321/304/304L/314/316/316L/310/310S/430 Duplex UNS S31803/S32205/S32750/S32760 enz. Groottebereik: Overdosis:10...
Productdetails
Markeren:
DN200 Duplex ruitbuis
,F51 Dubbelstaalbuis
Product Name:
Duplex het Roestvrije staalbuis van DN200 ASTM A790 F51/van F55/van F53/van F60
Keyword:
duplexstaalpijp
Type:
naadloos en gelast
Shape:
ronde
Length:
Vanaf Gevraagde Cliënt
Material:
SS201/301/302/321/304/304L/314/316/316L/310/310S/430 duplexuns S31803/S32205/S32750/S32760 Enz.
Application:
Decoratie, Bouw, Industrie, Chemische, Vloeibare Pijp
End:
Duidelijk
Productbeschrijving
DN200 ASTM A790 F51 / F55 / F53 / F60 Duplex roestvrijstalen buis
Productnaam: DN200 ASTM A790 F51 / F55 / F53 / F60 Duplex roestvrijstalen buis
Standaard: ASTMA790
Materiaal: SS201/301/302/321/304/304L/314/316/316L/310/310S/430 Duplex UNS S31803/S32205/S32750/S32760 enz.
Groottebereik:
Overdosis:10.3mm - 1219mm
W.T.:1.24 mm - 59.54 mm
Lengte: per verzoek van de klant.
Toepassing:Rails, balustrades, meubels, hekken, decoratie, constructies, voedingsmiddelenindustrie enz.
Chemische samenstelling, %
| UNS-benaming | C | - Jawel. | Deeltjes | P | S | Cr | Ni | Mo. | N | C. |
| max. | max. | max. | max. | max. | ||||||
| S31803 (F51) | 0.03 | 1 | 2 | 0.03 | 0.02 | 21.0 - 23.0 | 4.5 tot en met 6.5 | 2.5 tot en met 3.5 | 0.08 naar 0.20 | - |
| S32205 (F60) | 0.03 | 1 | 2 | 0.03 | 0.02 | 22.0 - 23.0 | 4.5 tot en met 6.5 | 3.0 tot en met 3.5 | 0.14 - 0.20 | - |
| S32750 (F53) | 0.03 | 0.8 | 1.2 | 0.035 | 0.02 | 24.0 - 26.0 | 6.0 tot 8.0 | 3.0 tot en met 5.0 | 0.24 tegen 0.32 | 0.5 max |
| S32760 (F55) | 0.05 | 1 | 1 | 0.03 | 0.01 | 24.0 - 26.0 | 6.0 tot 8.0 | 3.0 tot en met 4.0 | 0.20 tegen 0.30 | 0.50 -1.00 |
| DN | NPS ((inches) | D ((mm) | SCH5S | SCH10S | SCH40S | Geslachtsziekten | SCH40 | SCH80 | XS | SCH80S | SCH160 | XXS |
| 100 | 4 | 114.30 | 2.11 | 3.05 | 6.02 | 6.02 | 6.02 | 8.56 | 8.56 | 8.56 | 13.49 | 17.12 |
| 125 | 5 | 141.30 | 2.77 | 3.40 | 6.55 | 6.55 | 6.55 | 9.53 | 9.53 | 9.53 | 15.88 | 19.05 |
| 150 | 6 | 168.30 | 2.77 | 3.40 | 7.11 | 7.11 | 7.11 | 10.97 | 10.97 | 10.97 | 18.26 | 21.95 |
| 200 | 8 | 219.10 | 2.77 | 3.76 | 8.18 | 8.18 | 8.18 | 12.70 | 12.70 | 12.70 | 23.01 | 22.23 |
| 250 | 10 | 273.10 | 3.40 | 4.19 | 9.27 | 9.27 | 9.27 | 15.09 | 12.70 | 12.70 | 28.58 | 25.40 |
