Duidelijk Beëindigen 12M Ss van Max Length 41CR4 CDW Naadloze buis
Basis eigenschappen
Plaats van herkomst:
CHINA
Merknaam:
Torich
Certificering:
TS16949 ISO14001 ISO9001
Modelnummer:
GB/T8163
Handelsgoederen
Minimale bestelhoeveelheid:
10tons
Prijs:
onderhandelbaar
Betalingsvoorwaarden:
L/C, T/T
Toeleveringsvermogen:
60000tons per jaar
Productoverzicht
Seamless Tube Machining Steel Tube 41CR4 41CR S45C 45# Graad Precision Steel Tubes CDW Naadloze buisbewerking van staalbuis 41CR4 41CR S45C 45# Naadloze mechanische buis (SMT)/naadloze hydraulische buis (SHT) Groottelijst: OD 16 X ID 5,50 mm OD 18 X ID 5,45 mm OD 20 X ID 6,05 mm OD 30 X ID 6,35 mm ...
Productdetails
Markeren:
CDW-Ss Naadloze buis
,41CR4 Ss Naadloze buis
,Duidelijke Beëindigen Naadloze Ss Pijp
Material:
1020 1010 10# 20#
O.D.:
76600mm
W.T.:
6-50
Length:
maximum 12m
End:
Duidelijk
Surface:
Niets
Productbeschrijving
Seamless Tube Machining Steel Tube 41CR4 41CR S45C 45# Graad Precision Steel Tubes CDW
Naadloze buisbewerking van staalbuis 41CR4 41CR S45C 45#
Naadloze mechanische buis (SMT)/naadloze hydraulische buis (SHT)
Groottelijst:
OD 16 X ID 5,50 mm
OD 18 X ID 5,45 mm
OD 20 X ID 6,05 mm
OD 30 X ID 6,35 mm
OD39.5X ID7.5mm
20Cr:
C: 0,18-0.24
Si: 0,17-0.37
Mn: 0,50-0.80
P: min 0.035
S: 0.035
Cr: 0,70-1.00
Ni: 0.30
Cu: 0.30
Mo: 0.15
40Cr:
C: 0.37-0.44
Si: 0,17-0.37
Mn: 0,50-0.80
P: 0.035
S: 0.035
Cr: 0,80-1.00
Ni: 0.30
Cu: 0.30
Mo: 0.15
Toepassing:
