ASTM A519 koudgetrokken naadloze hydraulische buizen van koolstofstaal
Basis eigenschappen
Plaats van herkomst:
China
Merknaam:
TORICH
Certificering:
ISO 9001 ISO 14001 EN 10204 3.1 TS 16949 CCS
Modelnummer:
En10305-1
Handelsgoederen
Minimale bestelhoeveelheid:
5 ton
Prijs:
onderhandelbaar
Toeleveringsvermogen:
6000 ton één jaar
Productoverzicht
ASTM A519 EN10305-1 koud getrokken precieze naadloze buis voor hydraulisch systeem Snelle details: Koudgetrokken naadloze precisiestaalpijpen voor hydraulisch systeem OD:4-420 (mm) WT0.5-80 ((mm) Lengte 1000-12000mm Staalklasse: E215, E235, E355 Productnaam: S Koudgetrokken naadloze precisiestaalpij...
Productdetails
Markeren:
Koudgetrokken Staalbuis
,koudgetrokken buizen
Length:
100012000mm
Material:
Carbon Steel
Application:
voor Hydraulische Systemen
OD:
4-80 (mm)
WT:
0.5-10 (mm)
Productbeschrijving
ASTM A519 EN10305-1 koud getrokken precieze naadloze buis voor hydraulisch systeem
Snelle details:
Koudgetrokken naadloze precisiestaalpijpen voor hydraulisch systeem
OD:4-420 (mm) WT0.5-80 ((mm) Lengte 1000-12000mm
Staalklasse:
E215, E235, E355
Productnaam: S
Koudgetrokken naadloze precisiestaalpijpen
Toepassing: voor hydraulische systemen
| Precieze stalen buizen voor hydraulisch systeem-Standaard grootte grafiek | ||
| OD (mm) | WT (mm) | Lange (mm) |
| 4 | 0.5 | 5800-6000 |
| 4.0 | 1.0 | 5800-6000 |
| 5.0 | 1.0 | 5800-6000 |
| 6.0 | 1.0 | 5800-6000 |
| 6.0 | 1.5 | 5800-6000 |
| 8.0 | 1.0 | 5800-6000 |
| 9.5 | 0.89 | 5800-6000 |
| 10 | 0.8 | 5800-6000 |
| 10.0 | 1.0 | 5800-6000 |
| 10.0 | 1.5 | 5800-6000 |
| 10.0 | 2.0 | 5800-6000 |
| 12 | 0.8 | 5800-6000 |
| 12.0 | 1.0 | 5800-6000 |
| 12.0 | 1.2 | 5800-6000 |
| 12.0 | 1.5 | 5800-6000 |
| 12.7 | 0.8 | 5800-6000 |
| 12.7 | 1.2 | 5800-6000 |
| 13.0 | 1.5 | 5800-6000 |
| 13.5 | 2.0 | 5800-6000 |
| 14 | 1 | 5800-6000 |
| 14.0 | 1.5 | 5800-6000 |
| 15.0 | 1.0 | 5800-6000 |
| 16.0 | 1.5 | 5800-6000 |
| 16.0 | 2.0 | 5800-6000 |
| 16.0 | 2.5 | 5800-6000 |
| 16.0 | 3.0 | 5800-6000 |
| 16.0 | 3.5 | 5800-6000 |
| 17.2 | 2.0 | 5800-6000 |
| 17.2 | 3.0 | 5800-6000 |
| 18.0 | 3.0 | 5800-6000 |
| 20.0 | 1.5 | 5800-6000 |
| 20.0 | 2.0 | 5800-6000 |
| 20.0 | 2.5 | 5800-6000 |
| 20.0 | 3.5 | 5800-6000 |
| 22.0 | 1.5 | 5800-6000 |
| 22.0 | 3.0 | 5800-6000 |
| 25.0 | 1.5 | 5800-6000 |
| 25.0 | 2.5 | 5800-6000 |
| 25.0 | 3.0 | 5800-6000 |
| 25.0 | 3.5 | 5800-6000 |
| 25.0 | 4.0 | 5800-6000 |
| 28.0 | 1.5 | 5800-6000 |
| 28.0 | 3.0 | 5800-6000 |
| 28.0 | 3.7 | 5800-6000 |
| 30.0 | 1.5 | 5800-6000 |
| 30.0 | 2.5 | 5800-6000 |
| 30.0 | 3.5 | 5800-6000 |
| 30.0 | 4.0 | 5800-6000 |
| 32.0 | 1.0 | 5800-6000 |
| 32.0 | 1.5 | 5800-6000 |
| 32.0 | 3.0 | 5800-6000 |
| 32.0 | 4.7 | 5800-6000 |
| 32.0 | 5.0 | 5800-6000 |
| 35.0 | 3.0 | 5800-6000 |
| 36.0 | 4.7 | 5800-6000 |
| 38.0 | 2.5 | 5800-6000 |
| 38.0 | 4.0 | 5800-6000 |
| 38.0 | 4.7 | 5800-6000 |
| 40.0 | 2.0 | 5800-6000 |
| 40.0 | 2.5 | 5800-6000 |
| 40.0 | 4.0 | 5800-6000 |
| 40.0 | 5.7 | 5800-6000 |
| 42 | 1.5 | 5800-6000 |
| 42.0 | 4.0 | 5800-6000 |
| 42.0 | 6.7 | 5800-6000 |
| 45 | 2.5 | 5800-6000 |
| 46.0 | 5.5 | 5800-6000 |
| 50 | 2.5 | 5800-6000 |
| 50.0 | 6.0 | 5800-6000 |
| 50.0 | 8.0 | 5800-6000 |
| 52.0 | 7.0 | 5800-6000 |
| 55 | 2.5 | 5800-6000 |
| 56.0 | 4.1 | 5800-6000 |
| 57.0 | 8.0 | 5800-6000 |
| 60 | 2 | 5800-6000 |
| 62.0 | 7.0 | 5800-6000 |
