De Koude van de spoorwegbouw vormde Naadloos Staal Vierkant Buizenstelsel ASTM A500

Basis eigenschappen
Plaats van herkomst: China
Merknaam: Torich
Certificering: ISO 9001:2008 , TS16949 , ABS , CCS , DNV , GL
Modelnummer: Naadloze Vierkant en Rechthoek
Handelsgoederen
Minimale bestelhoeveelheid: 5MT
Prijs: onderhandelbaar
Betalingsvoorwaarden: L / C, T / T
Toeleveringsvermogen: 7000MT/Month
Productoverzicht
Naadloze stalen vierkantbuizen voor spoorwegconstructies, speciale stalen buizen Standaard: ASTM A500 staal rechthoekige buizen Koudgevormd gespannen en naadloos geconstrueerde koolstofbuizen in ronde vormen Toepassingen: voor de bouw van bruggen,Voor algemene structurele doelstellingen Grootte: ...

Productdetails

Markeren:

structureel staal vierkant buizenstelsel

,

rechthoekige stalen buis

Dimension:: 20-20 tot 500-500mm*1-24mm*12000mm
Steel Grade:: GradeA, GradeB, Gesorteerde GradeC,
Application:: Voor bouw van bruggen, en gebouwen, en voor algemene strcutrual doeleinden
Standard:: ASTM A500
Productbeschrijving

Naadloze stalen vierkantbuizen voor spoorwegconstructies, speciale stalen buizen

Standaard: ASTM A500 staal rechthoekige buizen
Koudgevormd gespannen en naadloos geconstrueerde koolstofbuizen in ronde vormen

Toepassingen:

voor de bouw van bruggen,Voor algemene structurele doelstellingen

Grootte:
Vierkant buis overdosis. :20-20 tot 500-500 mm W.T.:1-24 mm L:max12000 mm
Een overdosis rechthoekige buizen. :20-30 tot 400-600 mm W.T.:1-24 mm L:max12000 mm

Verplichtingen inzake de spanning
Ronde structuurbuizen
Graad A Klasse B Graad C Graad D
Strengte van de trekkracht,min,psi ((Mpa) 45 (310) 58 ((400) 62(425) 58 ((400)
Kracht van het vermogen,min,psi ((Mpa) 33(230) 42(290) 46(315) 36 ((250)
Verlenging in 2 inch. ((50 mm) min, % 25 23 21 23

Structurele buizen met een vorm

Graad A Klasse B Graad C Graad D
Strengte van de trekkracht,min,psi ((Mpa) 45 (310) 58 ((400) 62(425) 58
Kracht van het vermogen,min,psi ((Mpa) 39(270) 46(315) 50(315) 36 ((250)
Verlenging in 2 inch. ((50 mm) min, % 25 23 21 23
