Incoloy 800 Alloy Stalen Naadloze Pijpen
Basis eigenschappen
Plaats van herkomst:
Zhejiang China
Merknaam:
TORICH
Certificering:
ISO 9001
Modelnummer:
GB/T 30059
Handelsgoederen
Minimale bestelhoeveelheid:
5 ton
Prijs:
USD 1200-1500 Per Ton
Betalingsvoorwaarden:
Bevestigingsbrief, D/A, D/P, T/T, Western Union, MoneyGram
Toeleveringsvermogen:
500 Ton per maand
Productoverzicht
Productbeschrijving: Voor warmtewisselaar GB/T 30059 Incoloy 800 Inconel 600 naadloze corrosiebestendige legeringsbuizen China Inconel Steel Tube fabrikant, kies de hoge kwaliteit Inconel Steel Pipe, Incoloy Steel Tube, Black Carbon Steel Welded Pipe, Oval Steel Tube etc. Groottebereik: OD: 6-219 ...
Productdetails
Markeren:
Inconel 600 Buis
,Inconel 601 Buis
OD:
6219mm
WT:
0,5-10 mm
Length:
212m
Material:
Incoloy 800, Incoloy 825, Inconel 600 Et
Productbeschrijving
Productbeschrijving:
Voor warmtewisselaar GB/T 30059 Incoloy 800 Inconel 600 naadloze corrosiebestendige legeringsbuizen
China Inconel Steel Tube fabrikant, kies de hoge kwaliteit Inconel Steel Pipe, Incoloy Steel Tube, Black Carbon Steel Welded Pipe, Oval Steel Tube etc.
Groottebereik:
OD: 6-219 mm
WT: 0,5-10 mm
Lange: 2000-12000 mm
Onze normale maat: 26,7x2,87mm, 6,35x1,65mm, 25x2mm etc.
Staalklasse/staalmateriaal:
| Staalklasse | ASTM-staalklasse | C | Cr | Ni | Fe | Mo. | C. | Al | Ti | Nb | Co. | - Jawel. | Deeltjes | P | S |
| NS1101 |
N08800 (Incoloy 800) |
≤ 0.010 | 19.0-23.0 | 30.0-35.0 | Overige | - | ≤ 0.75 | 0.15-0.60 | 0.15-0.60 | - | - | ≤ 1.00 | ≤ 1.50 | ≤ 0.030 | ≤ 0.015 |
| NS1102 | N08810 (Incoloy 800H) |
0.05-0.10 | 19.0-23.0 | 30.0-35.0 | Overige | - | ≤ 0.75 | 0.15-0.60 | 0.15-0.60 | - | - | ≤ 1.00 | ≤ 1.50 | ≤ 0.030 | ≤ 0.015 |
| NS1103 | - | ≤ 0.030 | 24.0-26.5 | 34.0-37.0 | Overige | - | - | 0.15-0.45 | 0.15-0.60 | - | - | 0.30-0.70 | 0.50-1.50 | ≤ 0.030 | ≤ 0.030 |
| NS1401 | - | ≤ 0.030 | 25.0-27.0 | 34.0-37.0 | Overige | 2.0-3.0 | 3.0-4.0 | - | 0.40-0.90 | - | - | ≤ 0.70 | ≤ 1.00 | ≤ 0.030 | ≤ 0.030 |
| NS1402 | N08825 (inkoloy 825) |
≤ 0.05 | 19.0-23.5 | 38.0-46.0 | ≥ 22.0 | 2.5-3.5 | 1.5-3.0 | ≤ 0.20 | 0.60-1.20 | - | - | ≤ 0.50 | ≤ 1.00 | ≤ 0.030 | ≤ 0.015 |
| NS3102 | N06600 (Inconel 600) |
≤ 0.15 | 14.0-17.0 | Overige | 6.0-10.0 | - | ≤ 0.50 | - | - | - | - | ≤ 0.50 | ≤ 1.00 | ≤ 0.030 | ≤ 0.015 |
| NS3105 | N06690 (Inconel 690) |
≤ 0.05 | 27.0-31.0 | Overige | 7.0-11.0 | - | ≤ 0.50 | - | - | - | - | ≤ 0.50 | ≤ 0.50 | ≤ 0.030 | ≤ 0.015 |
| NS3306 | N06625 (Inconel 625) |
≤ 0.10 | 20.0-23.0 | Overige | ≤ 50 | 8.0-10.0 | - | ≤ 0.40 | ≤ 0.40 | 3.15-4.15 | ≤ 1.00 | ≤ 0.50 | ≤ 0.50 | ≤ 0.015 | ≤ 0.015 |
Mechanische eigenschappen:
| Staalklasse | ASTM-staalklasse | Mechanische eigenschappen | ||
|
Treksterkte Rm/MPa |
Kracht van de opbrengst RP0.2/MPa |
Verlenging A/% |
||
| ≥ | ||||
| NS1101 | N08800 (Incoloy 800) |
517 | 207 | 30 |
| NS1102 | N08810 (Incoloy 800H) |
448 | 172 | 30 |
| NS1103 | - | 515 | 205 | 30 |
| NS1404 | - | 540 | 215 | 35 |
| NS1402 | N08825 (inkoloy 825) |
586 | 241 | 30 |
| NS3102 | N06600 (Inconel 600) |
552 | 241 | 30 |
| NS3105 | N06690 (Inconel 690) |
586 | 241 | 30 |
| NS3306 | N06625 (Inconel 625) |
690 | 276 | 30 |
Leveringsvoorwaarden:
Gekoeld en gepekeld, helder gegekoeld, koud getrokken of koud gewalst
Geplateerde buizen Kenmerken:
Hoge sterkte
Gemakkelijk te vormgeven
Corrosiebestendig
Stabiele kwaliteit
Glanzige ruwheid
TORICH Kwaliteitsborging
Productieprocessen:
Naadloos koud getrokken of naadloos koud gewalst + warmtebehandeling van gegrilde en gekruide, heldere gegrilde
Koud getrokken of koud gewalst
Ruwe staal:
Productielijn:
Eddy-stroomtest en ultrasone test:
Kwaliteitsinspectie in laboratorium:
Verpakking:
